Introducing SKEL: The SimKube Expression Language

This is what the inside of an octopus looks like, right???

We just released SimKube 2.5.0, which as I said on Mastodon, feels like a big milestone for mainly “I like round numbers” reasons; but I think this is actually a pretty major release, as it’s the first SimKube release to include support for a bespoke DSL that I’m calling SKEL, or the SimKube Expression Language. SKEL opens up a lot of really interesting possibilities for SimKube, so I wanted to spend some time in this post talking about it!

Why do we need SKEL?

As one of my friends likes to say, WPAYS? This is an extremely dumb acronym that stands for “What Problem Are You Solving?”, which is nevertheless an important question to ask in many situations. In this case, the Problem I’m Solving™️ is that SimKube trace files (which, as you may recall from previous hot garbage like Anatomy of a Trace, form the heart of the record-and-replay functionality in SimKube) are really hard to work with.

The main issue at play is that trace files are saved in the msgpack format, which is a binary file format that is similar, but not completely identical to, JSON. The decision to use msgpack was made extremely early on in the life of SimKube; I was looking for a file format that would be relatively compact but also easy to work with¹, and the tagline on the msgpack website is “It’s like JSON, but fast and small,” and that sounded great to me. And, to be fair, it is both of those! The size difference between a SimKube trace file and the equivalent JSON text file is about 70%²! The main problem is that, unlike JSON and jq, there are no really ubiquitous tools for manipulating msgpack files. The best thing I’ve found is msgpack-tools, which lets you convert between msgpack and JSON; and, up until recently, that has been how I’ve worked with my trace files: convert the trace to JSON, make some changes, and convert back to msgpack.

This approach is fine, except that a) it’s not very user-friendly, and b) the msgpack schema and the JSON schema are very similar, but they are not identical. One of the big differences is that msgpack allows integer-valued map keys and JSON does not. And, in an unfortunate-but-somewhat-painful-to-fix design decision, SimKube trace files use integer map keys to track pod lifecycle events: that is, information like “this pod ran for this many seconds before terminating with this error code”. Because pod names are not a stable identifier, we use a hash of the pod spec to identify these lifecycle events, and that hash appears as a map key in the trace.

This is a problem for msgpack-tools: it can write out a JSON-like text file that includes these integer map keys, but it is completely unable to convert back to the msgpack format from this JSON-like text file because it first tries to parse the text file as JSON. This means that my “write to pseudo-JSON, make some changes, write back to msgpack” workflow is now entirely broken.

If it’s so hard, how does anybody else ever work with msgpack???

The main way that msgpack appears to be used in other applications is a serialization format for over-the-wire communication: meaning that you’ve got two programs on either end of a network connection that need to talk to each other. So, while msgpack doesn’t have a lot of CLI tools to support its use, it does have libraries to support serializing and deserializing msgpack for basically every programming language on the planet. So one option that I considered for solving the “trace modification problem” is “just make people write code”. We could provide a “SimKube trace modification library” that handles some standard sorts of operations, but otherwise allows users to write code to change the trace how they see fit using a msgpack library of their choice. This has the advantage of being extremely flexible, because users can do whatever they want to the trace, but also a bit of a usability nightmare: users now have to understand the internal trace file format, and if that format ever changes, it’s gonna break a ton of scripts³.

So instead, I opted for a narrower approach that still gives users flexibility, but doesn’t require them to understand the full internal workings of the trace file, and gives me the ability to change things about the trace file format in the future without breaking things for existing users: a domain-specific language. This approach, while requiring a bit more up-front work on my side, also means that I don’t have to provide “simkube libraries” for every programming language under the sun; I can continue to use Rust for everything, and users just have to learn an entirely new language all on their own! That seems like a fair tradeoff, right? Right???

Designing SKEL

I’ve not written a full-fledged DSL before, so this was also just an exciting opportunity for me to dip my toes in a new area of computer science. Before I started this whole project, I was dimly aware that there were things like “abstract syntax trees” and “lexers” and “parsers” and a whole bunch of other nonsense. But before diving into any of those details, I decided to just settle on a syntax for SKEL. I wanted the language to be relatively simple and intuitive, but I also knew that I had a wide variety of operations that it needed to be able to support. I tried to make sure that the syntax could handle all of the transformations that I knew I needed, as well as being relatively extensible for the future.

To keep the language simple and tractable to implement, I set a few requirements for myself:

1. Statements should be executed independently of each other; the only coupling between statements is how the impacts the underlying trace file⁴

2. There is no flow control (no loops, no conditionals, no gotos): every SKEL file is executed one line at a time in order

3. Since we’re focused on modifying trace files, each statement needs two parts: a selector, which specifies what bits of the trace file to operate on, and an action, which says what to do with those bits.

I went through a few different options, including more of a SQL-like syntax, but I finally settled on a functional approach based on the third criteria above. Every statement in SKEL has the following syntax⁵:

function(selector, action);

A SKEL file then just looks like a sequence of these statements. The supported functions are pretty self-explanatory; right now we just support two, remove and modify; the remove function un-sets a field in the matching objects, and the modify function changes the value of a field in the matching objects. All of the magic is what happens inside these function calls.

SKEL selectors

If you recall from earlier posts on this blog, a SimKube trace is just a timeline of events: each event has a timestamp and a list of Kubernetes resources to apply or delete. So naturally, there are two types of selectors that SKEL supports: timestamp selectors and resource selectors. Timestamp selectors use the magic variable @t, and you can write any sort of relative or absolute query using this variable; @t > 5m means “all the events after the 5-minute mark in the trace file”, for example.

Resource selectors are a bit more complicated, but just slightly; a SKEL resource selector uses jq-style “dot-notation” to dig into the internals of a Kubernetes resource: metadata.labels."simkube.dev/whatever" == "foo"⁶ selects all of the resources in the trace that have a simkube.dev/whatever=foo label assigned to them. And of course, you can combine these two selectors: @t > 5m && metadata.labels."simkube.dev/whatever" == "foo" means “select all resources in the trace that were changed after 5 minutes, and have the appropriate label applied to them”.

The epiphany that I had while designing the syntax was that SKEL selectors define a set of events; the right way to think about writing SKEL commands is to decide what set of events you are trying to target, and then narrow in on that set using the && operator. But, sometimes, in order to narrow in on the set of events, you need to be able to reference other fields in the resource. For example, you might want to target all resources that have a node selector matching the value of a particular label on that resource. This is where SKEL variables come into play!

$x := metadata.labels."simkube.dev/whatever" | exists($x)
    && spec.template.spec.nodeSelector.myNodeSelector == $x

Here, we are defining a variable $x⁷ that points to the value of the simkube.dev/whatever label; every statement in a SKEL selector must be a boolean, so in this case we just assert that this label is actually set on the object, and discard it otherwise. Then, the second statement narrows the scope to only target resources whose myNodeSelector matches the value of the simkube.dev/whatever label applied to that resource. This is very cool, in my opinion!

There’s one last feature that SKEL selectors support, which are wildcards. Some Kubernetes fields (like the containers field in the PodSpec) are arrays; we can target individual elements of those arrays using standard bracket notation (e.g., spec.template.spec.containers[2]), but in some cases we may want to target every element of an array; we can do that using the * wildcard. For example, spec.template.spec.containers[*].image == "ubuntu:latest" targets every container using the ubuntu:latest Docker image.

You can also mix-and-match variables and wildcards:

$x := spec.template.spec.containers[*] | $x.image == "ubuntu:latest"

defines $x as the set of full container specifications whose image field is ubuntu:latest. Super cool! I love how a (relatively) small set of selection operations has given rise to a very rich ecosystem of capabilities.

SKEL actions

This section is comparatively shorter than the selectors section; that’s because, once you’ve defined a set of events and resources to take action on, actually performing those actions is pretty straightforward. For example,

remove(metadata.labels."simkube.dev/whatever" == "foo", spec.template.spec.nodeSelector);

just removes the nodeSelector field from every resource with the simkube.dev/whatever=foo label applied to it. Similarly, the modify command would allow you to change the value of the nodeSelector instead of removing it. Of course, variables and wildcards also work inside the “action” side of the command, which lets you build up extremely targeted operations to your trace file as well.

Implementing SKEL

I’ll try to keep this section brief, but for all you programming language theory nerds out there⁸ I’ll talk a bit about the implementation details of SKEL. The core library that I’m using is called pest, which continues in the grand tradition of “cool Rust projects with really questionable names”⁹. Pest implements a Parsing Expression Grammar library in Rust. To use it, you define the DSL grammar in a .pest file, and Pest will automagically convert the grammar into a set of Rust enums representing all of the grammar’s rules. So, for example, one of the PEG rules in my pest file looks like the following¹⁰:

conditional_test = { resource_path ~ comparator ~ (val | resource_path) }

This defines a grammar rule called conditional_test (accessed in the Rust code as Rule::conditional_test), and a conditional_test consists of a resource_path followed by a comparator, and either an atomic value (like a string or an integer) or another resource_path¹¹.

One of the interesting things about Pest is that the library itself asserts which rules are valid in which positions, so it is idiomatic in Pest code to sprinkle .unwrap()s and unreachable!()s everywhere based on where you are in the parsed expression. This takes a bit of getting used to.

Now if you know anything about designing programming languages, you’re probably expecting that the next words out of my mouth are going to be “abstract syntax tree”. But, you’d be wrong. An abstract syntax tree is a data structure that, more-or-less¹², lets you unambiguously specify order of operations: in other words, all those pesky rules you learned in grade school about whether you add things before you multiply things. However, for SKEL, this turns out to be entirely unnecessary: there is one unambiguous way to parse a SKEL file, and that’s from left-to-right. I no longer have an abstract syntax tree, I have more of an… abstract syntax path. This turns out to be very handy. It means that all of the logic for SKEL is contained in about 2000 lines of code, much of which is pretty straightforward “convert this Rule into this data structure”.

Anyways, once I’ve loaded everything into my ASP, I can just traverse through all the statements in the file and apply them to the input trace one-by-one. The mechanics of this are pretty straightforward, the most complicated bits were just about keeping track of the variable state so that I can correctly know which variables are defined at which point in time, and to what values they point.

There was one open question about the order in which statements should be applied: should I apply each statement to the entire trace file before moving on to the next one? Or should I loop through the trace file once, and apply every statement in order to each event? In the interest of “keeping statements and effects local”, I elected for the former; in other words, once an event in the trace has been processed by all SKEL statements, it will never be touched again. It “feels like” this will be easier to reason about in the long run, but I don’t actually know for sure.

Deleting code feels good man

I’ll just wrap this post up by saying that SKEL is actually the second attempt I’ve made to solve this problem; about a year ago, I wrote a bunch of code to “validate” a trace file, and confirm that it won’t cause any common problems in a simulation (example of a common problem: a Pod needs a Secret injected as an environment variable, but the Secret isn’t defined in the simulation environment, which probably you do not actually want, and the value of the Secret doesn’t actually matter anyways because there’s no code running in the Pod to use the Secret). One of the features in this validator allowed users to auto-apply fixes to the generated trace; unfortunately, for every class of problems, there are many different types of fixes that you could apply. In the Secret example above, for instance, you could either remove the secret from the pod specification, or you could create the secret with a placeholder value at the beginning of the simulation. And who knows? Maybe neither of these solutions is what you actually want to do.

The logic to keep track of these potential fixes, and which once were applicable at which times to what events, was some of the ugliest, most complicated code in the entire codebase. I had visions of expanding the feature, and eventually making it so that you could even have user-editable “fixes”, but the code was so gross already that I just kindof abandoned it. It worked! But it wasn’t pretty and I didn’t want to add anything else to it.

However, with the advent of SKEL, I was finally able to just rip all that out and simplify a lot of things: now, instead of auto-fixing issues, the SimKube validation code just prints out a sample SKEL file that will address the issues that were detected in the trace; users can look at that and decide whether those are the correct fixes, or if they’d like something different. Then they can modify it how they’d like before applying the transformations and running a simulation. Even with all the complexity of the DSL and everything, this is a much better approach! And I’m very happy about it.

Everything we’ve talked about is now available in SimKube 2.5.0 and there’s a bunch more details in the documentation as well, but this has been a really fun new addition to SimKube, and I think it’s going to open up a lot of possibilities in the future!

I hope you enjoyed reading this as much as I enjoyed building it, and as always—thanks for reading.

~drmorr

1. I was also looking for something that wasn’t protobuf, cuz I hate dealing with that format.

2. You can get it down even smaller, to about 99% compression if you run the msgpack trace file through gzip compression; if you were to just gzip the equivalent JSON file, you “only” get about 94% compression.

3. You know, because by that point I’ll be wildly successful and will have dozens of people using SimKube!

4. This decision “might” be a bad one; the implication is that the order of your statements matters. If you modify all the pods to remove the simkube.dev/whatever label, and then later select pods based on the simkube.dev/whatever label, it will select nothing. On the other hand, if you reverse the order of the statements, the selection set will be non-empty.

5. Yes, all statements end with a semi-colon. Don’t at me, bro.

6. Since most Kubernetes labels, annotations, and a few other fields use domain names (e.g. simkube.dev) for namespacing, there has to be a way for SKEL to differentiate between the usage of periods, hence the double-quotes around the label key.

7. Perl called, they want their dollar signs back.

8. I know some of you follow this blog, don’t even try to hide it.

9. Other projects in this category include: clap, anyhow, rustls (seriously, how do you even pronounce that???), and, of course, SimKube.

10. Brand new sentence.

11. If you’re curious, you can see the full grammar file on GitHub.

12. I am not a programming languages person, but I am 100% convinced that all of you who are PL people are already getting out your wallets to become paid subscribers so you can tell me how wrong I am in the comments.
