Writing Better Design Docs
Welcome back, and happy March! I've been dealing with a bunch of sortof gnarly design decisions with SimKube recently, and so I thought this week I'd talk about my approach to writing design docs since I started Applied Computing1. In this post, we'll a) talk about what I think design docs should achieve, b) talk about what to do with all the other crap that you need to write down when you're starting a new project that doesn't belong in the design doc, and c) walk through an example doc I've written for SimKube.
Design docs: What are they good for? (huh!)
I've written a lot of design docs over the years, and my opinions on them have evolved significantly in that time, so let's talk about how I work on projects and how I use design docs to help with my process. But first, some history: back when I was a baby engineer, the first design doc I ever wrote was essentially to get permission to refactor a terrible codebase into a slightly less terrible codebase. As is common at most places, there was a design doc template2 that had all kinds of irrelevant fields, like "What is your database schema?" and "What are the security implications you need to consider?" and I was like, "Idk, man, I just want to move some code from this file to that file."
The problem with "design docs" at most companies3 is that they're trying to do too many things for too many people and so they end up just being bad at all of them. They are a) explaining the background and problem space, b) describing at a high level the proposed solution or project, c) trying to justify why this particular problem is the correct one, d) trying to make a prioritization argument for why this project should be done instead of other projects, e) providing an in-depth technical specification for the project, f) describing the public API and/or user experience for the project, g) trying to articulate important trade-offs or decisions that need to be made, h) responding to security concerns, i) describing how the project will be productionized (monitoring, alerting, all that jazz), j) describing the rollout plan, k), describing the project timeline and important milestones along the way, and l) I dunno, your company probably has some other random requirements in here that I didn't cover. Whew!
Now don't get me wrong—all of those topics are important topics to consider, and definitely require some form of communication to your stakeholders. It may be the case that that communication should be written down, but it doesn't have to be written down for each of those categories. It really depends on the context that the project is being considered in. But what I can say with absolute certainty is that if you try to have one document answer all of those questions, you're going to end up with a 20+ page Google doc that nobody is going to read, is tonally all over the place, and will provide basically anyone in the company the opportunity to hamstring your project because they don't like this one section that you probably just pulled out of a hat because actually implementing that part is two years away and who knows what's going to change between now and then4.
So, if we all agree that we've had too many 20+ page Google docs in our lives, let me talk about ways that we can still write about our technical designs without resorting to the canonical design doc. At Applied Computing, I don't write design docs; instead, I write what I've taken to calling "Technical Decision Records"5. What's that?
A technical decision record is a narrowly scoped1 document that aims to answer2 between one and three3 closely related4 technical5 questions about a project's design.
There's a bunch of load-bearing words in that definition, so let's break it down a bit more.
Narrowly scoped: The decision record should have a single focus area that it's trying to resolve. If there are bunch of unrelated open questions about your design, then you should have one technical decision record6 for each.
Answer: Maybe this goes without saying, but the goal of one of these documents is to help you make a decision! If you don't need to make a decision, or worse, at the end of the process you haven't made a decision, why are you wasting your time???
One and three: This is related to the first point, but I find that limiting my scope to at most three questions helps me keep the focus on a single topic. If I find myself needing more than three questions, that's a signal that maybe I need to break the problem down further. This isn't a hard and fast rule, though, if you have four questions you need to answer nobody's going to come after you.
Closely related: Have I said this needs to be a tightly-focused document enough times yet?
Technical: It's in the name, y'all. Similar ideas probably work for non-technical decisions that you need to make, but a technical decision record needs to talk about the technical aspects of your problem. Stuff like "milestones" and "rollout plans" etc., can and should influence your technical decisions but you shouldn't use this document to articulate what your rollout plan is going to be.
The most important thing here is that you don't write a technical decision record until you have a decision to make. If the path forward is obvious or straightforward? Don't write a document, just do it. If you know you'll need to eventually make a decision, but you don't need to know the answer right now? Don't write the document! Nobody's going to care and you might have new information by the time you actually need to make the decision.
"But drmorr," I hear you saying. "What about all that other stuff? Don't all of those other things play into your technical decisions?" Absolutely they do. The technical decisions you make will should 100% be influenced by your project's prioritization, your organization's security posture, your target customer experience, etc. You can even reference these factors in your decision record. But those should be separate pieces of communication.
"But drmorr," I hear you saying again7. "If those are in separate documents, and someone doesn't know about those other documents, and they come across your <grimace>TDR</grimace>, how will they be able to understand the context behind it?"
This is a great question, but it's a different problem than what I'm trying to solve. The question you just asked me is about documentation discoverability. I can't tell you how to solve this problem, but what I can tell you is that if you try to solve the discoverability problem by stuffing everything into a single Google doc, that's how you end up with 20+ page Google docs that nobody reads8.
Example: A SimKube decision record
In this section, I'm going to show you an example of a decision record I recently wrote up for SimKube so you can get an idea of how I approach these documents. I'm going to break this down into sections and cover each section one-at-a-time with some commentary thrown in the middle. Contents from the design doc itself are quoted, and my commentary is in the regular style. For context, this design doc is one that I wrote when I was trying to reason about how to get data out of SimKube for future analysis, and is what ultimately led to the creation of prom2parquet.
Note that I cut some of the sections down for length purposes, but if you want to follow along and read the entire document, you can find that here.
What problem are we solving?
We want to be able to perform data analysis on Kubernetes scheduling and autoscaling behaviour.
Ok, first up I define the scope of the document. This is a one or two sentence high level description of the problem I'm trying to solve, and helps set the stage for the rest of the doc.
What steps do we need to take to get there?
We need to be able to import data from (say) multiple scheduling simulations
We need to be able to compute metrics and nice visualizations based on the input data
We need to be able to save all of the data analysis somewhere persistent (S3)
Now we're starting to scope things down a bit more. These are essentially our hard requirements, and generally correspond closely to the questions we're trying to answer.
What questions do we need to answer?
Ok, here they are; I have three questions defined in this particular document.
Where do we get the data from?
Basically the “only” option we have here is Prometheus. Any other solution for scraping metrics involves us re-inventing a huge amount of stuff that Prometheus already does.
The real question here is, how do we get fine-enough-grained data so that we can do some reasonable analysis on it? We need at a minimum 1s resolution, I think. We can’t expect users to run their existing prometheus at 1s `scrape_interval, so this essentially means we have to launch our own Prometheus pod per simulation.
Option 1: rely on the prometheus operator
pros: this is what we’re already using in our stack, I think it’s not super hard to create a new prometheus object in sk-ctrl that targets the things we want.
cons: we introduce a dependency on the prometheus operator into SimKube.
Option 2: construct either fireconfig, helm, or raw YAML to ship
pros: no extra dependency needed
cons: ugh.
Decision: we’re not expecting users to run this in their production clusters, simulation clusters are supposed to be ephemeral, so we can care a little less about another dependency in here. Let’s do the Prometheus operator because it’s easier. At some point down the line, if someone complains, we can revisit.
Ok, above you see the rough format I follow for each of the questions. I put the question I want to answer in bold, I (optionally) write down a bit of extra context9, and then write down all the options I can think of. It's important to write down all the options, even if you're reasonably sure you're not going to take one of them. You're brainstorming here. There aren't any dumb options.
Once I've written down all the options I can think of, I go back to each and write down all the pros and cons I can think of for each option. Sometimes you end up with "pro of option A is con of option B" and vice versa, but I'd encourage you to try to think a little bit deeper than that. Each option you write down probably has some advantages or disadvantages that just aren't present in the other options. Figure out what those are and write them down.
By this point, the very act of writing down all the options may have made it obvious what you need to do, so go ahead and write down your decision. Note here that I explicitly call out in my decision that it's OK to revisit later if we need to. If I'm in doubt about a decision, I tend to err towards the decision that lets me course-correct later the easiest. If you still don't know what the right answer to your question is, that's ok! Leave the decision blank and go on to the next question.
How do we get the data out?
Option 1: dump the TSDB
Option 2: targeted export
Maybe Option 3: can we provide “export hooks” in the simulation?
Decision: let’s try going down the Option 3 route and see how far that gets us.
Update: we ended up using Prometheus remote write targets, which basically let users send their data anywhere they want. The remote write targets need to be set up outside of SimKube, which is maybe a bit annoying, but I don’t really want SimKube to be responsible for configuring this.
For the sake of "trying not to make this post too long", this is an abridged version of what I actually wrote down. There are two things I want to call out about this section. The first is that the original decision I made basically says "I don't know what the right answer is, let's try to collect more data." This is a fantastic outcome from a decision record! Remember, the whole point of this document is to try to help you make a decision, and if you truly don't have enough information to make the decision, then your next step is to either a) pick something because you don't have time or it's not important enough, or b) go collect the data that you need.
The second thing I want to call out here is that I went back and updated the decision record once I got that data. This document isn't just to help you make the decision, it's also to provide context for anyone else (maybe even you) who comes along six months later to understand why you made the decision that you did. I know this is a little bit annoying to do, but your future self will thank you for it.
What format do we want to store the data in (while we’re doing the analysis? After we’re done?)
…
I'm eliding the last section for length reasons, but I just want you to notice that I'm not using particularly formal writing here in this document, either. Part of that is because my only audience for this doc is me, but also it's partly because formal writing takes time and I'm trying to drive to a decision quickly. So I don't worry (much) about proper grammar, punctuation, I throw in words like "ugh", I have excessive parentheses, all of the stuff that I would cut out if this were a more formal document. What matters here is not the formatting, it's the content. So get the content right and who cares about the formatting.
Yo dawg, I heard you like design docs…
So there you have it! A design doc for your design docs. I don't know that any of the ideas I wrote about in this post are particularly new—you can definitely find other people who advocate for similar formats or ideas all over the Internet, but for some reason it doesn't seem like they stick at a lot of companies. I think maintaining a healthy, iterative, uh, agile10 culture requires a lot of strict discipline and support from leadership, and it's not always immediately obvious what the benefit is (in fact, sometimes the short-term benefit is negative, because you have to tell somebody "No, I'm not sticking that in my design doc template"). So I can see why it's hard to do, particularly at larger organizations. But, if you can make it happen, your engineers will thank you.
Anyways, that's all I've got for this week! Thanks for reading,
~drmorr
What, you thought just because I'm the only employee and I basically get to do whatever I want that I'm throwing all sense of decorum and best practice out the window? I can't believe you have such a low opinion of me. My code even has unit tests!
Stop me if you've heard this one before.
And possibly also with how they're taught in university, I dunno, I changed majors primarily so that I didn't have to take the class where we learned how to write design docs.
I swear, if I had a nickel for every time I've written something in a design doc where I said to myself, "Please God don't ever let me have to actually implement this," I'd probably have, idk, ten nickels or something.
I really wanted something that acronymized to "TPS Report", but I couldn't think of anything.
I am working extremely hard to not abbreviate this as TDR, because that's just too corporate for me.
My goodness you're whiny today.
Shocking everyone, I do have some opinions on discoverability, actually, which basically boil down to "all your documentation for a project should live in the same place." Maybe they're all in the same Notion teamspace, or all under the same Confluence or wiki heading, or all in the same folder in Google drive. You can also aggressively use links between documents to aid in discoverability. Oh, and your technical specification should just be an API doc that lives next to your code. But hopefully the API docs get published somewhere so that they're easy to link to from everything else.
Note here that I'm actually refining the question I'm trying to answer in the second bullet point.
Ugh, fine, I said it.
