SimKube: Part 2 - Virtual Kubelet and the Brain
Author's Note: This post is now somewhat out of date, since we are no longer using Virtual Kubelet inside SimKube, but instead using Kubernetes WithOut Kubelet (KWOK). KWOK turns out to be somewhat more efficient than VK at large scale, and is a bit more full-featured for our purposes. I'm leaving this post up for posterity, but may write a follow-up in the future describing how we work with KWOK.
This is the second part of a (at least) four-part series on simulation in Kubernetes. Here’s the outline of the rest of the series, I will update this with links to future posts as I write them:
Part 1 (last week) - Why do we need a simulator?
Part 2 (this week) - Building a simulated cluster with Virtual Kubelet
Part 3 (in two weeks) - Recording traces and replaying them
Part 4 (i dunno when) - Analyzing the data
Want to get notified when the rest of this series is published? Subscribe below!
Introducing Virtual Kubelet
In my last post, I outlined the problem space and hopefully explained why having a working, scalable simulator for Kubernetes will be useful. In this post, I’m going to dive into the implementation. All the source code that I’m talking about here is available on our GitHub repo if you want something to reference as we go along. And, full disclosure, this post involves a lot of staring at kubectl output, so I won’t be offended if you give it a pass :)
The core component that we’re relying on for our simulator is the Virtual Kubelet. This was a project that was originally started by folks at Microsoft to allow the management of different Azure resources through the Kubernetes API, and has now been extended to provide access to a bunch of different “external” resources via the Kubernetes API. The way it works is by running a pod on your Kubernetes cluster that exposes a fully-conformant kubelet1 API. So, to the Kubernetes API server, it just sees another node that’s been added to the cluster, but from our perspective, that “node” can be anything we want—an interface to AWS Fargate or Azure Batch, a Hashicorp Nomad cluster, or, say, a mocked-out interface that doesn’t actually do anything2.
Here’s the interface that a virtual kubelet implementation has to satisfy (for conciseness I’m omitting the context argument to each function):
type PodLifecycleHandler interface {
CreatePod(pod *corev1.Pod) error
UpdatePod(pod *corev1.Pod) error
DeletePod(pod *corev1.Pod) error
GetPod(namespace, name string) (*corev1.Pod, error)
GetPodStatus(namespace, name string) (*corev1.PodStatus, error)
GetPods() ([]*corev1.Pod, error)
}This is a pretty straightforward set of CRUD operations: the first three handle your “write” operations, and the last three let you read data about pods running on the fake node. Since we’re not actually going to run anything, the implementation for our virtual nodes is going to be straightforward:
type podLifecycleHandler struct {
nodeName string
pods map[string]*corev1.Pod
}All we have to do is maintain a map from pod name to pod objects that are “running” on the node. CreatePod inserts the pod object into this map3, and DeletePod removes it from the map. UpdatePod currently does nothing, though I may extend it in the future. The various Get... operations just query the map and return the matching results.
The other half of the puzzle we need to solve is how to configure the node object that we are presenting. Virtual Kubelet exposes a NodeController object which creates the node object inside etcd and handles all of the node updates. So all we have to do is tell the controller what our fake node “looks” like:
nodeCtrl, err := node.NewNodeController(
node.NaiveNodeProvider{},
n, // <------ this is the node!
self.k8sClient.CoreV1().Nodes(),
node.WithNodeEnableLeaseV1(leaseClient, 0),
)Here, n is a *corev1.Node, which is what will be returned when you run kubectl describe node. The cool part here is that SimKube takes as input a Kubernetes node object in YAML format, and uses that as to construct the node in etcd! So as a simulation runner, you can configure the nodes in your simulated cluster to match exactly what you have running in production: all you have to do is kubectl describe a node in production, and then pipe that in to the virtual kubelet pod! I think this is nifty.
So let’s take a look at how all the pieces fit together. Here is the SimKube virtual kubelet pod in my cluster (I’m cutting out all the irrelevant parts for brevity):
> kubectl get pods
NAMESPACE NAME READY STATUS RESTARTS AGE
simkube sk-vnode-q 1/1 Running 0 13h
...
> kubectl describe pod sk-vnode-q
Namespace: simkube
Node: test-worker/172.18.0.4
Labels: app=sk-vnode
pod-template-hash=7bc95f4479
Annotations: <none>
Containers:
sk-vnode:
Command:
/sk-vnode
Args:
--node-skeleton
/config/node.yml
State: Running
Started: Wed, 30 Aug 2023 21:05:52 -0700
Ready: True
Mounts:
/config from node-skeleton (rw)
Volumes:
node-skeleton:
Type: ConfigMap (a volume populated by a ConfigMap)
Name: sk-vnode-configmap
Optional: falseNothing too surprising here, we have a pod scheduled on the test-worker node, running the /sk-vnode command, and taking some configuration from a node skeleton file. Let’s see that file real quick:
> kubectl exec sk-vnode-q -- cat /config/node.yml
---
apiVersion: v1
kind: Node
status:
allocatable:
cpu: "1"
memory: "1Gi"
capacity:
cpu: "1"
memory: "1Gi"So we’re creating a node that has a single CPU and 1Gi of memory. Now let’s see what nodes we actually have in the cluster:
> kubectl get nodes
NAME STATUS ROLES AGE VERSION
sk-vnode-q Ready agent,virtual 13h v1.27.1
test-control-plane Ready control-plane 2d v1.27.1
test-worker Ready <none> 2d v1.27.1Well this is interesting! I’ve got three nodes in my cluster, a control plane node, a worker node, and a node that has the same name as the pod up above! It’s marked as having a “virtual” role. What does it look like?
> kubectl describe node sk-vode-q
Name: sk-vnode-q
Roles: agent,virtual
Labels: beta.kubernetes.io/arch=amd64
beta.kubernetes.io/os=linux
kubernetes.io/arch=amd64
kubernetes.io/hostname=sk-vnode-q
kubernetes.io/os=linux
node-role.kubernetes.io/agent=
node-role.kubernetes.io/virtual=
node.kubernetes.io/instance-type=m6i.large
simkube.io/node-group=sk-vnode
simkube.io/node-group-namespace=simkube
topology.kubernetes.io/region=us-east-1
topology.kubernetes.io/zone=us-east-1a
type=virtual
CreationTimestamp: Wed, 30 Aug 2023 21:05:52 -0700
Taints: simkube.io/virtual-node=true:NoExecute
Unschedulable: false
Capacity:
cpu: 1
ephemeral-storage: 1Ti
memory: 1Gi
pods: 110
Allocatable:
cpu: 1
ephemeral-storage: 1Ti
memory: 1Gi
pods: 110
System Info:
Machine ID:
System UUID:
Boot ID:
Kernel Version:
OS Image:
Operating System:
Architecture:
Container Runtime Version:
Kubelet Version: v1.27.1
Kube-Proxy Version:
ProviderID: simkube://sk-vnode-q
Non-terminated Pods: (2 in total)
Namespace Name CPU Requests CPU Limits Memory Requests Memory Limits Age
--------- ---- ------------ ---------- -------------------- ------------- ---
kube-system kube-proxy-k5ws6 0 (0%) 0 (0%) 0 (0%) 0 (0%) 13h
simkube test-deploy-a 1 (100%) 0 (0%) 0 (0%) 0 (0%) 13h
Allocated resources:
(Total limits may be over 100 percent, i.e., overcommitted.)
Resource Requests Limits
-------- -------- ------
cpu 1 (100%) 0 (0%)
memory 0 (0%) 0 (0%)
ephemeral-storage 0 (0%) 0 (0%)
Events: <none>Again, I snipped a bunch of stuff out for brevity, but you can see that this “more or less” looks like a normal node. It’s got all the standard labels applied, along with a label and a taint that mark this node as “virtual”, and you can see that just like we specified in our config, it’s advertising 1 CPU and 1Gi of RAM. It fills in some other stuff by default (for example, it picks up the kubelet version from the actual Kubernetes version of the cluster, and it’s advertising as an m6i.large instance type), but these can be overridden via the node skeleton file. You can also see that the CreationTimestamp for the node matches the Started time of the pod above. Nifty!
And, what’s this? If we look at the running/non-terminated pods, we see two have been scheduled on this node, and are “running”. The first is a kube-proxy Daemonset, and the second is something called test-deploy-a. Let’s take a look at that:
> kubectl describe pod test-deploy-a
Name: test-deploy-a
Namespace: simkube
Priority: 0
Service Account: default
Node: sk-vnode-q/
Labels: app=test
pod-template-hash=5d44b6c577
Annotations: <none>
Status: Running
Containers:
nginx:
Image: nginx:latest
State: Running
Started: Wed, 30 Aug 2023 21:06:44 -0700
Ready: True
Requests:
cpu: 1
Mounts:
/var/run/secrets/kubernetes.io/serviceaccount from kube-api-access-b6z2n (ro)
Conditions:
Type Status
PodScheduled True
Initialized True
ContainersReady True
Ready True
Volumes:
kube-api-access-b6z2n:
Type: Projected (a volume that contains injected data from multiple sources)
TokenExpirationSeconds: 3607
ConfigMapName: kube-root-ca.crt
ConfigMapOptional: <nil>
DownwardAPI: true
Node-Selectors: type=virtual
Tolerations: node.kubernetes.io/not-ready:NoExecute op=Exists for 300s
node.kubernetes.io/unreachable:NoExecute op=Exists for 300s
simkube.io/virtual-node=true:NoExecute
Events: <none>As you can see, this is a pretty standard pod: it’s running nginx, it’s marked that it’s running, all the conditions have been set correctly, it has a volume mount, it’s using up a CPU… basically everything that you would expect to work on a pod just works out of the box. You can also see that this pod has a node selector and a toleration so that it must be scheduled onto our virtual node. Very cool!
But wait, it gets better.
Now that we’ve got the basic building block in place, we can start to do even more cool things. Our virtual kubelet pod is running inside a Deployment, and deployments can scale up and down, which means we can introduce autoscaling into our simulation! It turns out that this is also easy to do. The Kubernetes Cluster Autoscaler can interface with a couple dozen different cloud providers, but it also has a pluggable interface that lets users define their own cloud providers! So we’re going to create a cloud provider that’s backed by our virtual kubelet deployment.
The interface we have to satisfy here is a bit more involved, but it’s not too bad. I’m again going to omit function args, return values, and a few methods for brevity:
service CloudProvider {
rpc NodeGroups()
rpc NodeGroupForNode()
rpc NodeGroupNodes()
rpc Refresh()
rpc NodeGroupTargetSize()
rpc NodeGroupIncreaseSize()
rpc NodeGroupDeleteNodes()
rpc NodeGroupDecreaseTargetSize()
}As a quick refresher, Cluster Autoscaler operates on a set of NodeGroups, such that all nodes within a single NodeGroup must have identical characteristics. The core autoscaling loop looks for a set of “feasible” NodeGroups that could accommodate an unschedulable pod, and then through an interface called an Expander, picks one of those NodeGroups to scale up.
Thus, the above CloudProvider interface allows us to accomplish all of those tasks for an arbitrary cloud provider via gRPC calls to an external service: in this case, a virtual cloud provider. The implementation for these methods is straightforward, so I’m not going to go through them here. It uses label selectors to identify the node groups (aka Deployments) and nodes within those node groups (aka Pods) that are available for scaling, and then it updates the number of replicas in the deployment to scale up or down.
The only tricky bit here is on scale-down: when Cluster Autoscaler wants to remove nodes from a cluster, it looks for empty nodes or nodes whose workloads can be scheduled elsewhere in the cluster, and terminates those nodes first (it would obviously not be great if the autoscaler just started deleting random nodes!) But in a Kubernetes deployment, the decision on which pods to terminate on scale-down is essentially random.
But! In Kubernetes 1.22 a new feature called Pod Deletion Cost was moved into beta. This feature allows you to set a “cost” on pods within a ReplicaSet, and pods with lower cost will be deleted first by the ReplicaSet controller. So all our virtual cloud provider has to do on scale-down is set this deletion cost annotation, and everything else just works. Let’s take a look at how this works!
> kubectl get pods
NAMESPACE NAME READY STATUS RESTARTS AGE
simkube sk-vnode-q 1/1 Running 0 13h
simkube test-deploy-a 1/1 Running 0 13h
> kubectl -n kube-system get pods | grep cluster-autoscaler
kube-system cluster-autoscaler 1/1 Running 0 45hOk, now you can see that cluster-autoscaler is running in my cluster, along with our previous virtual node and the test deployment4. Let’s go ahead and scale that test deployment up:
> kubectl scale deployment test-deploy --replicas 5
deployment.apps/test-deploy scaled
> kubectl get pods
NAMESPACE NAME READY STATUS RESTARTS AGE
simkube sk-vnode-q 1/1 Running 0 13h
simkube test-deploy-a 1/1 Running 0 13h
simkube test-deploy-b 0/1 Pending 0 4s
simkube test-deploy-c 0/1 Pending 0 4s
simkube test-deploy-d 0/1 Pending 0 4s
simkube test-deploy-e 0/1 Pending 0 4sAs expect, the new pods in the deployment are unschedulable — each of them requests 1 CPU, they can only be scheduled on virtual nodes, and our virtual nodes are only exposing 1 allocatable CPU each. We can confirm this by looking at the scheduling events:
> kubectl describe pod test-deploy-e
...
Events:
Type Reason Age From Message
---- ------ ---- ---- -------
Warning FailedScheduling 6m13s default-scheduler 0/3 nodes are available: 1 Insufficient cpu, 1 node(s) didn't match Pod's node affinity/selector, 1 node(s) had untolerated taint {node-role.kubernetes.io/control-plane: }.Now let’s deploy our virtual cloud provider, and see what happens:
> kubectl apply -f sk-cloudprov.yml
deployment.apps/sk-cloudprov created
> kubectl get pods
NAMESPACE NAME READY STATUS RESTARTS AGE
simkube sk-cloudprov 1/1 Running 0 6s
simkube sk-vnode-q 1/1 Running 0 13h
simkube test-deploy-a 1/1 Running 0 13h
simkube test-deploy-b 0/1 Pending 0 8m45s
simkube test-deploy-c 0/1 Pending 0 8m45s
simkube test-deploy-d 0/1 Pending 0 8m45s
simkube test-deploy-e 0/1 Pending 0 8m45sAnd then, a few seconds later…
> kubectl get pods
NAMESPACE NAME READY STATUS RESTARTS AGE
simkube sk-cloudprov 1/1 Running 0 6s
simkube sk-vnode-q 1/1 Running 0 13h
simkube sk-vnode-w 1/1 Running 0 49s
simkube sk-vnode-e 1/1 Running 0 49s
simkube sk-vnode-r 1/1 Running 0 49s
simkube sk-vnode-t 1/1 Running 0 49s
simkube test-deploy-a 1/1 Running 0 13h
simkube test-deploy-b 1/1 Running 0 10m
simkube test-deploy-c 1/1 Running 0 10m
simkube test-deploy-d 1/1 Running 0 10m
simkube test-deploy-e 1/1 Running 0 10m
> kubectl get nodes
NAME STATUS ROLES AGE VERSION
sk-vnode-q Ready agent,virtual 13h v1.27.1
sk-vnode-w Ready agent,virtual 53s v1.27.1
sk-vnode-e Ready agent,virtual 53s v1.27.1
sk-vnode-r Ready agent,virtual 53s v1.27.1
sk-vnode-t Ready agent,virtual 53s v1.27.1
test-control-plane Ready control-plane 2d v1.27.1
test-worker Ready <none> 2d v1.27.1Awwwww yea.
Wrapping Up
I know this post was more technical and included a lot of staring at kubectl output, but I am pretty excited about this progress! If you want to play with it yourself, you can duplicate all the same steps using the code on our GitHub repo. Also of note: I’m going to be at KubeCon NA in Chicago in November this year, and I’m giving a talk where I’ll be going over some of this same content, and (hopefully) presenting a live demo! So look me up if you’re going to be there too. Next time, we’ll take a look at how we can use this simulated cluster to replay “live” traces of a production environment.
As always, thanks for reading.
~drmorr
Recall that kubelet is the process that runs on every host in your cluster and is responsible for starting a pod running on the host, as well as performing the last set of admission controls to make sure that the pod is allowed to run on the host. It’s the equivalent to the borglet from Google’s internal distributed system, Borg.
This is the same idea as the hollow node from the kubemark test suite, but as (hopefully) we’ll see soon, we’re going to extend our virtual kubelet “nodes” to provide a lot more functionality than kubemark hollow nodes.
We have to do a little bit of extra work here to ensure that the pod and container statuses are set correctly, but it’s not hard to do.
Astute readers will have noticed in my last kubectl get pods code block that I sneakily elided the test deployment from the output so as to set up the dramatic reveal later on. >:)
